PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
51
MAIN DOOR INTERIOR (B)
ITEM PART DESCRIPTION
HT2 (501E)
HT3 (501E)
13 Coin Return Bracket 631,001,39x.x3 631,050,18x.x3
14 Coin Return Rocker 631,001,38x.x3 631,050,17x.x3
15 Roller Pin 900,502,19x.x1 900,502,19x.x1
16 Roller Pin Retainer 900,900,90x.x1 900,900,90x.x1
17 Coin Return Spring 901,700,63x.x1 901,700,63x.x1
18A Top Coin Chute Assembly (HT2 only) 631,005,60x.x3 NA
18B Coin Insert Chute Cover (HT3 only) NA 801,814,39x.x1
18C Coin Insert Chute (HT3 only) NA 801,814,40x.x1
19 Coin Discharge Ramp 631,001,34x.x3 801,814,35x.x1
20 Lower Coin Chute 631,001,36x.x3 801,814,36x.x1
21 Coin Mech Mounting Plate 631,001,22x.x3 631,050,13x.x1
22 Carriage Bolt, ¼ 20 x ½ 900,201,45x.x1 900,201,45x.x1
23 Keps nut ¼ 20 900,800,67x.x1 900,800,67x.x1
24 Gasket, 1/8 x 1/8 x 36 801,814,27x.x1 801,814,27x.x1
25 Screw, 8-18x1/2 SD Phil Pan 900,301,50x.x1 900,301,50x.x1
26 Screw, 8-32x1/4 Phil Pan 900,301,97x.x1 900,301,97x.x1
27 Keps Nut 8-32 900,800,50x.x1 900,800,50x.x1
28 Deflector, Coin – (Metal) 631,001,44x.x3 NA
