PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
53
SELECT PANEL
ITEM
PART DESCRIPTION HT2 (501E)
HT3 (501E)
1 Select Panel Assy., Right (shown) Pepsi 631,004,20x.x3
631,051,60x.x3
Select Panel Assy., Right (shown) Mtn. Dew NA
631,050,60x.x3
2 Select Panel Assy., Left (not shown) Pepsi 631,005,40x.x3
631,051,70x.x3
Select Panel Assy., Left (not shown) Mtn. Dew NA
631,055,10x.x3
3 Upper Switch/Button Bracket 631,001,29x.x3
631,050,16x.x3
4 Lower Switch/Button Bracket 631,001,31x.x3
NA
5 Stud Select Panel Assembly, Left Pepsi 631,005,10x.x3
631,051,90x.x3
Stud Select Panel Assembly, Left Mtn. Dew NA
631,055,20x.x3
6 Stud Select Panel Assembly, Right Pepsi 631,004,60x.x3
631,051,80x.x3
Stud Select Panel Assembly, Right Mtn. Dew NA 631,055,00x.x3
7 Select Switch 804,101,08x.x1 804,101,08x.x1
8 Select Button 801,814,01x.x1 801,814,01x.x1
9 Sold out Light 804,700,75x.x1 804,700,75x.x1
10 Sold out Light Mount 801,814,15x.x1 801,814,15x.x1
11 Button Return Spring 801,306,04x.x1 801,306,04x.x1
12 Philpan Sems Screw 6-32 x 1 800,303,35x.x1 800,303,35x.x1
13 Gasket, 1/4 x .154 x 13 801,814,25x.x1 801,814,25x.x1
14 Gasket, 1/8 x 1/8 x 27 801,814,24x.x1 NA
15 Gasket, 1/8 x 1/8 x 13.5 801,814,26x.x1 NA
16 8-32 Keps Nut 900,800,50x.x1 900,800,50x.x1
17 Wire Tie 7 1/2 “ 901,902,01x.x1 901,902,01x.x1
