PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
57
ELECTRONICS COMPONENTS
ITEM PART DESCRIPTION HT2 (501E)
HT3 (501E)
1 Electronic Lock Assembly 805,202,44x.x1 805,202,44x.x1
2 Electronic Lock Light Pipe 801,814,19x.x1 801,814,19x.x1
3 Machine Controller 804,918,15x.x1
631,053,30x.x3
4 Machine Controller Base 801,813,45x.x1
801,306,15x.x1
5 Machine Controller Cover 631,000,68x.x3
801,306,16x.x1
6 Universal Controller 804,916,31x.x1
NA
7 Display (Vacuum Fluorescent) 804,918,69x.x1 804,918,69x.x1
8 Transformer 804,909,80x.x1 804,909,80x.x1
9 Machine Controller EPROM 804,917,61x.x1
NA
10 Universal Controller EPROM 804,916,25x.x1
NA
11 Fuse 6 Amp (F2) 804,910,93x.x1 804,910,93x.x1
12 Fuse 1.6 Amp (F1) 804,800,71x.x1 804,800,71x.x1
13 Control Board Assembly HT3 NA
631,053,30x.x1
14 HT3 Eprom Control Board NA
804,919,24x.x1
