PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
59
INNER DOOR
ITEM PART DESCRIPTION HT2 (501E)
HT3 (501E)
1 Inner Door Assembly 631,004,90x.x3 631,004,90x.x3
2 Inner Door Gasket 801,804,06x.x1 801,804,06x.x1
3 Discharge Frame Assembly 801,809,16x.x1 801,809,16x.x1
4 Discharge Frame Retainer 801,809,15x.x1 801,809,15x.x1
5 Pull Knob 901,501,70x.x1 901,501,70x.x1
6 Carriage Bolt ¼-20x¼ 900,201,23x.x1 900,201,23x.x1
7 Inner Door Bushing 801,806,42x.x1 801,806,42x.x1
8 Bushing Retainer 801,806,43x.x1 801,806,43x.x1
9 Plastic Bearing 901,803,71x.x1 901,803,71x.x1
10 Top Hinge 169,053,00x.x3 169,053,00x.x3
11 Bottom Hinge 169,051,10x.x3 169,051,10x.x3
12 Inner Door Lock Kit 360,010,30x.x4 360,010,30x.x4
