PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
63
HARNESSING
Single Board (HT3)
ITEM PART DESCRIPTION HT3 (501E)
2 Motor Extension Harness, 90” (see page 61) 804,909,29x.x1
2 Motor Harness (see page 61) 804,912,56x.x1
4 Cabinet Harness (see page 61) 804,912,57x.x1
4 Cabinet Extension Harness, 80 inches J4 to (see page 61) 804,913,96x.x1
5 Board Power Harness (including transformer) J1 (see page 61)
804,909,80x.x1
7 Harness Electronic Lock (see page 61) 804,918,28x.x1
8 Jumper Electronic Lock (see page 61) 804,918,66x.x1
9A Select Switch Harness 1 – 6 (Jumper off common) 804,919,17x.x1
9B Select Switch Harness 7 – 12 (Jumper off common) 804,919,18x.x1
9C Select Switch Common Harness (P4 to select switches) 804,919,16x.x1
11 66” DEX Harness 804,907,83x.x1
13 Temp Sensor & Relay Harness 804,919,22x.x1
14 Display Harness (P3 to display board) (not shown) 804,919,21x.x1
16 Secondary DEX Harness 804,913,97x.x1
17 Sold Out Light Kit 631,053,50x.x3
18 MDB and Lock Power Harness (P8 & P5 to coin mech & lock) 804,919,19x.x1
