PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
65
CABINET AND VEND MECHANISM
(SECTION ONE)
ITEM DESCRIPTION HT2 (501E)
HT3 (501E)
1 Vend Motor Cover Assy. 609,070,43x.x3 609,070,43x.x3
1A Clamp Nylon Cable 3/4 (2) not shown 901,900,55x.x1 901,900,55x.x1
2A Vend Motor Assy., Wide HVV (Electronic) 609,070,70x.x3 609,070,70x.x3
2B Vend Cam, Wide Column Grey 801,809,80x.x1 801,809,80x.x1
2C Adjustable Cam, Wide Column Red 801,809,79x.x1 801,809,79x.x1
3A Vend Motor Assy., Narrow HVV (Electronic) 609,070,90x.x3 609,070,90x.x3
3B Vend Cam, Narrow Column Brown 801,806,18x.x1 801,806,18x.x1
3C Adjustable Cam, Narrow Column Brown 801,806,61x.x1 801,806,61x.x1
4 Vend Motor Switch Switch Electronic 804,100,73x.x1 804,100,73x.x1
5 Vend Motor Switch Insulator 905,800,33x.x1 905,800,33x.x1
6 Vend Rotor - Narrow Column 801,201,56x.x1 801,201,56x.x1
7 Vend Oscillator - Wide Column 801,201,57x.x1 801,201,57x.x1
7A Package Retainer - Oscillator 801,807,87x.x1 801,807,87x.x1
8 Nyliner
Front Wide Column Only (#8L2-FF) 901,804,23x.x1 901,804,23x.x1
Rear All Columns 801,803,17x.x1 801,803,17x.x1
9 Rod and Spring Assembly 800,503,00x.x1 800,503,00x.x1
10 Tubes for Rod and Spring Assy.
Red 801,903,23x.x1 801,903,23x.x1
Yellow 801,903,25x.x1 801,903,25x.x1
White 801,903,24x.x1 801,903,24x.x1
Black 801,904,04x.x1 801,904,04x.x1
11 Vend Motor Cover Trim 801,807,85x.x1 801,807,85x.x1
12 Rear Air Deflector 801,903,29x.x1 801,903,29x.x1
A6 Screw, Vend Motor #4-24x3/4 (single switch)
900,300,47xx.1 900,300,47xx.1
A9 Screw, Phil Pan 8-32x3/8 900,301,56x.x1 900,301,56x.x1
