PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
67
CABINET AND VEND MECHANISM
(SECTION TWO)
ITEM
DESCRIPTION HT2 (501E)
HT3 (501E)
1A Sold-Out Switch Assy. Electronic (w/ gold cross point) - Xenoy 1731 804,100,75x.x1 804,100,75x.x1
1B Sold-Out Paddle
Standard Emodel (shown) 432,070,19x.x3 432,070,19x.x3
Special Use Only - E-Models 609,070,19x.x3 609,070,19x.x3
Narrow - Special Use Only E-Models 432,070,17x.x3 432,070,17x.x3
1C Sold-Out Paddle Spring 901,700,74x.x1 901,700,74x.x1
2A Front, Left Mechanism Support (shown) 609,070,22x.x3 NA
2B Rear Mechanism Support (shown) 497,070,01x.x3 497,070,01x.x3
2C Front, Right Mechanism Support (not shown) 609,070,23x.x3 NA
3A Evaporator Fan Motor Assy.
115V 491,000,20x.x3 609,044,30x.x3
220-240V 491,140,40x.x3 NA
3B Evaporator Fan Motor
115V 609,044,40x.x3 804,501,12x.x1
220-240V / 50 Hz 609,044,60x.x3 609,044,60x.x3
3C Evaporator Fan Motor Bracket 164,040,08x.x3 164,040,08x.x3
3D Evaporator Fan Blade All Styles (AD775CW32S or FV775CW30S) 801,303,27x.x1 801,303,27x.x1
3E Evaporator Fan Harness 804,914,35x.x1 804,914,35x.x1
4 Wire Shield 267,070,37x.x3 267,070,37x.x3
5A Foam Block, EPS 903,300,77x.x1 903,300,77x.x1
5B Hinge Pocket Cover 169,000,13x.x3 169,000,13x.x3
6 Journal 176,072,11x.x3 176,072,11x.x3
7 Shims
Flat Shim 3/32" (wide column) Waffle 801,812,04x.x1 801,812,04x.x1
Short Flat Shim 3/32" (wide column) 801,809,81x.x1 801,809,81x.x1
Can Stop Shim, Right (narrow column) 805,701,14x.x1 805,701,14x.x1
Bottle Shim, Right (narrow column) 805,701,15x.x1 805,701,15x.x1
Bottle Shim, Right (narrow column) Expose Stiffener 801,304,96x.x1 801,304,96x.x1
Angle Shim (wide column) 610,070,06x.x3 610,070,06x.x3
Angle Shim (narrow column) 609,010,10x.x3 609,010,10x.x3
Rotor Shim 330 ml x 4 801,305,21x.x1 801,305,21x.x1
Shim 330 ml x 4 Can, Narrow Column 609,070,53x.x3 609,070,53x.x3
Can Stop Shim, 330 ml (3 deep) 609,070,71x.x3 609,070,71x.x3
Shim 25 cl x 4 Can, Narrow Column 609,070,56x.x3 609,070,56x.x3
Bottom Shim, Exposed Stiffener Extended Lip 609,070,65x.x3 609,070,65x.x3
Flat Shim 3/32 Large Product 801,811,05x.x1 801,811,05x.x1
Shim Back 609,071,02x.x3 609,071,02x.x3
Can Stop Shim Long Lip 609,070,64x.x3 609,070,64x.x3
8 Nyliner
Front Wide Column Only (#8L2-FF) 901,804,23x.x1 901,804,23x.x1
Rear All Columns 801,803,17x.x1 801,803,17x.x1
9 Chute, Can/Bottle HVV Plastic 609,077,80x.x1 609,077,80x.x1
9A Screw, 8-32x1/2 Sems Phil Pan 900,303,09x.x1 900,303,09x.x1
9B Strip, Poly Foam 34” (under chute) 803,301,30x.x1 803,301,30x.x1
A3 Screw, Phil Pan 10-32x5/16" 900,301,83x.x1 900,301,83x.x1
B5 Speed Nut (evaporator fan & condenser fan) 900,800,85x.x1 900,800,85x.x1
