PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
69
CABINET AND VEND MECHANISM
(SECTION THREE)
ITEM
DESCRIPTION HT2 (501E)
HT3 (501E)
1 Foam Cabinet Assy. Hvv 609,001,20x.x3 631,060,40x.x3
2A Stack Assy.
12 oz. Cans 609,071,20x.x3 609,071,20x.x3
20 oz. Bottles 609,071,50x.x3 609,071,50x.x3
330 ml Can 4 deep 609,074,40x.x3 609,074,40x.x3
2B Stack Sub Assy. (Not Shown) 609,071,10x.x3 609,071,10x.x3
3A Rear Spacer Assy. Wide Column 498,071,30x.x3 498,071,30x.x3
3B Rear Spacer Assy. Narrow Column 498,071,40x.x3 498,071,40x.x3
3C Latch Spring
Wide 901,700,88x.x1 901,700,88x.x1
Narrow 901,700,86x.x1 901,700,86x.x1
4A Plate, Protective LS Ext. Hinge (Specify Blue) 609,000,01x.x3 594,020,14x.x3
4B Plate, Protective RT Cab (Specify Blue) 165,000,04x.x3 165,000,04x.x3
5 Relay (Environmental Control Kit Only)
5A Relay (3) (Environmental Control Venders Only) 804,200,26x.x1 804,200,26x.x1
5B Plate Mounting Relay (used on all HVV Machines) 631,000,64x.x3 631,000,64x.x3
5C Filter (powerline) (All HT2 501E) 804,917,96x.x1 NA
5D Choke (Used on all HVV Machines ) (replaces Filter – 5C) 804,919,09x.x1 804,919,09x.x1
6A Label, Light Relay (Environmental Control Venders Only) 803,860,68x.x1 803,860,68x.x1
6B Label, Fan Relay (Environmental Control Venders Only) 803,860,69x.x1 803,860,69x.x1
6C Label, Compressor Relay (Environmental Control Venders Only) 803,860,70x.x1 803,860,70x.x1
7 Cabinet Front Stiffener Plate 594,021,10x.x3 594,021,10x.x3
8 Trim Access Hole Stiffener 801,807,10x.x1 801,807,10x.x1
9 Caterpillar Grommeting 801,809,93x.x1 801,809,93x.x1
10 Mullion 801,806,21x.x1 801,806,23x.x1
11 Mullion Cover 801,303,83x.x1 801,303,83x.x1
12 Kydex Door (not shown) 801,903,34x.x1 801,903,34x.x1
13 Choke / Relay Plate Assy. NA 631,007,30x.x3
A4 Screw, Phil Pan 8-18x1/2 900,301,50x.x1 900,301,50x.x1
A5 Screw, Phil Pan Swage Form #8-32x1/4" 900,301,97x.x1 900,301,97x.x1
A9 Screw, Phil Pan 8-32x3/8 900,301,56x.x1 900,301,56x.x1
A10 Screw, Machine #6-32x1 1/4" 900,201,31x.x1 900,201,31x.x1
A14 Screw, Phil Pan 10-32x1 1/4 900,301,81x.x1 900,301,81x.x1
A16 Screw, Phil Pan Sems 8-18x1/2" 900,301,65x.x1 900,301,65x.x1
A17 Screw, Type F 1/4-20x5/8 (Stack Bolts) 900,302,01x.x1 900,302,01x.x1
A19 Screw, Phil Pan 10-32x5/8 900,901,51x.x1 900,901,51x.x1
A21 Screw, Phil Pan 8-18x1/2 900,301,98x.x1 900,301,98x.x1
A26 Screw, Phil Pan 8-18x3/4 800,303,15x.x1 800,303,15x.x1
B2 Keps Nut 1/4"-20 900,800,67x.x1 900,800,67x.x1
C6 Lockwasher, Shakeproof 5/8" (1132-00-00-0551) 900,700,89x.x1 900,700,89x.x1
C8 Washer, Shakeproof (4610-16-01-0551) 900,700,62x.x1 900,700,62x.x1
E9 Carriage Bolt 1/4-20x5/8 800,303,19x.x1 800,303,19x.x1
F1 Pop Rivet, Aluminum 1/4" 901,100,43x.x1 901,100,43x.x1
F5 Pop Rivet, Steel (Zinc Plated) 1/8" 901,100,61x.x1 901,100,61x.x1
F6 Pop Rivet, Aluminum 1/8" 901,100,53x.x1 901,100,53x.x1
H2 Tinnerman Clip, Fan Shroud (C5207-014-3B) 900,901,89x.x1 900,901,89x.x1
H7 Hole Plug, Snap In - 1 1/4 801,807,01x.x1 801,807,01x.x1
I6 Clamp, Nylon 5/16 Black Heyco 3355 or Dennison 10159 900,901,79x.x1 900,901,79x.x1
I7 Clamp, Nylon 1/2" Heyco 3328 900,901,80x.x1 900,901,80x.x1
