PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
71
CABINET INTERIOR
ITEM DESCRIPTION HT2 (501E)
HT3 (501E)
1 Lock Housing
1A Assy. Vertical Recpt Mount 631,006,40x.x3 631,006,40x.x3
1B Plate Assy (Black) 801,306,05x.x1 801,306,05x.x1
1C Screw 1/4x20x1 900,301,73x.x1 900,301,73x.x1
1D Nut 1/4-20 Nylong Insert, Locking 800,303,48x.x1 800,303,48x.x1
1E E-Lock Shim 631,000,76x.x3 631,000,76x.x3
2 Gate, Wire 801,401,72x.x1 801,401,72x.x1
3 Wire Gate Latch Lock & Guide 801,401,77x.x1 801,401,77x.x1
4 Wire Gate Bracket Top 609,070,36x.x3 609,070,36x.x3
5 Label - Close Gate 805,029,45x.x1 805,029,45x.x1
6 Clamp, Nylon Cable 1/2" (Not Shown) 900,901,80x.x1 900,901,80x.x1
7 Leveling Leg 5/8"-11x2 1/16" 900,502,49x.x1 900,502,49x.x1
8 Mounting Bracket, Rear (Not Shown) 609,070,24x.x3 609,070,24x.x3
A4 Screw, Phil Pan 8-18x1/2 900,301,50x.x1 900,301,50x.x1
A5 Screw, Phil Pan Swage Form #8-32x1/4" 900,301,97x.x1 900,301,97x.x1
A9 Screw, Phil Pan 8-32x3/8 900,301,56x.x1 900,301,56x.x1
A10 Screw, Machine #6-32x1 1/4" 900,201,31x.x1 900,201,31x.x1
A14 Screw, Phil Pan 10-32x1 1/4 900,301,81x.x1 900,301,81x.x1
A16 Screw, Phil Pan Sems 8-18x1/2" 900,301,65x.x1 900,301,65x.x1
A17 Screw, Type F 1/4-20x5/8 (Stack Bolts) 900,302,01x.x1 900,302,01x.x1
A19 Screw, Phil Pan 10-32x5/8 900,901,51x.x1 900,901,51x.x1
A21 Screw, Phil Pan 8-18x1/2 900,301,98x.x1 900,301,98x.x1
A26 Screw, Phil Pan 8-18x3/4 800,303,15x.x1 800,303,15x.x1
B2 Keps Nut 1/4"-20 900,800,67x.x1 900,800,67x.x1
C6 Lockwasher, Shakeproof 5/8" (1132-00-00-0551) 900,700,89x.x1 900,700,89x.x1
C8 Washer, Shakeproof (4610-16-01-0551) 900,700,62x.x1 900,700,62x.x1
E9 Carriage Bolt 1/4-20x5/8 800,303,19x.x1 800,303,19x.x1
F1 Pop Rivet, Aluminum 1/4" 901,100,43x.x1 901,100,43x.x1
F5 Pop Rivet, Steel (Zinc Plated) 1/8" 901,100,61x.x1 901,100,61x.x1
F6 Pop Rivet, Aluminum 1/8" 901,100,53x.x1 901,100,53x.x1
H2 Tinnerman Clip, Fan Shroud (C5207-014-3B) 900,901,89x.x1 900,901,89x.x1
H7 Hole Plug, Snap In - 1 1/4 801,807,01x.x1 801,807,01x.x1
I6 Clamp, Nylon 5/16 Black Heyco 3355 or Dennison 10159 900,901,79x.x1 900,901,79x.x1
I7 Clamp, Nylon 1/2" Heyco 3328 900,901,80x.x1 900,901,80x.x1
