PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
73
HINGES AND ROLLER ASSY.
HT2 (501E)
1A Roller, Main Door
All Styles 901,806,20x.x1 901,806,20x.x1
1B Roller Pin
All Styles 900,502,19x.x1 900,502,19x.x1
2A Assy., Top Hinge (drop in pin) E-Models
All Styles Pepsi 609,051,40x.x3 609,051,40x.x3
All Styles Mtn. Dew NA 631,055,40x.x3
2B Top Hinge (drop in pin) E-Models
All Styles 801,304,92x.x1 801,304,92x.x1
2C Top Hinge Spacer
All Styles 169,000,15x.x3 169,000,15x.x3
2D Bearing Sleeve
All Styles 805,300,42x.x1 805,300,42x.x1
3A Bottom Hinge Sleeve
All Styles 900,502,64x.x1 900,502,64x.x1
3B Bottom Hinge Pin
Pepsi 900,502,70x.x1 900,502,70x.x1
3C Bottom Hinge Assy. Cabinet
Pepsi 801,304,90x.x1 801,305,07x.x1
4A Door Stop Pepsi NA 631,001,43x.x3
Door Stop Mtn. Dew NA 631,050,42x.x3
4B Door Stop Bracket Pepsi NA 592,051,19x.x3
Door Stop Bracket Mtn. Dew NA 631,050,41x.x3
A9 Screw, Phil Pan Swage Form #8-32x3/8" 900,301,56x.x1 900,301,56x.x1
A15 Screw, Machine Truss #10-32x1/2" 900,201,14x.x1 900,201,14x.x1
A17 Screw, Self Tapping 1/4-20x5/8" 900,302,01x.x1 900,302,01x.x1
B2 Keps Nut, 1/4-20 900,800,67x.x1 900,800,67x.x1
B4 Keps Nut, Top Door Hinge 3/8-16 900,800,69x.x1 900,800,69x.x1
B10 Hex Nut, 5/16-28 Center w/Flange (top hinge - drop in) 900,801,02x.x1 900,801,02x.x1
C2 Flat Washer Door Hinge (Bottom) 901,303,77x.x1 901,303,77x.x1
C10 Washer, Flat 18 Gauge 900,700,83x.x1 900,700,83x.x1
C11 Flat Washer, 14 Gauge 5/16"-3/8"x7/8" 900,700,08x.x1 900,700,08x.x1
E2 Carriage Bolt, 1/4-20x1 (Top Hinge) 900,201,17x.x1 NA
E6 Carriage Bolt 1/4-20x3/4" 900,201,56x.x1 900,201,56x.x1
E8 Carriage Bolt, 1/4-20x1 1/4 (top hinge - drop in) 900,201,85x.x1 900,201,85x.x1
E9 Carriage Bolt, 1/4-20x5/8" 800,303,19x.x1 800,303,19x.x1
Carriage Bolt, 1/4-20x1 1/4 (top hinge) NA 900,201,23x.x1
H5 Retainer, Roller Pin 900,900,90x.x1 900,900,90x.x1
