PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
75
REFRIGERATION SYSTEM
(SECTION ONE)
ITEM DESCRIPTION
HT2 (501E)
HT3 (501E)
1 Complete Refrigeration System
Domestic 1203 C-E 115/60 609,043,50x.x4 609,043,50x.x4
1/3 HP 220-240/50 "E" (1222B-E IEC) 609,040,20x.x3 609,040,20x.x3
1/3 HP 220-240/50 "E" (1222B-E AUS) 609,040,30x.x3 609,040,30x.x3
1/3 HP 220-240/50 "E" (1222B-E GEN) 609,040,40x.x3 609,040,40x.x3
2A Compressor
FFI12HBX 115/60 1/3 HP 802,501,74x.x1 802,501,74x.x1
FFI12HBK 220/50 1/3 HP 802,502,17x.x1 802,502,17x.x1
2B Compressor Lead Harness (Not Shown)
115/60 (1202CB-E) 904,900,61x.x1 904,900,61x.x1
Europe (1222B-E IEC) 804,905,32x.x1 804,905,32x.x1
IECA (1222B-E AUS) 804,904,49x.x1 804,904,49x.x1
220/50 (1222B-E GEN) 904,900,61x.x1 904,900,61x.x1
2C Compressor Mounting Grommet (Black) 902,000,57x.x1 902,000,57x.x1
2D Compressor Mounting Clip 900,901,88x.x1 900,901,88x.x1
2E Compressor Grommet Plug, Plastic 901,803,91x.x1 901,803,91x.x1
3A Condenser Base Plate 491,040,25x.x3 491,040,25x.x3
3B Condenser Fan Motor Assy.
115/60 491,040,20x.x3 491,040,20x.x3
220/50 491,140,30x.x3 491,140,30x.x3
3C Condenser Fan Motor Bracket (“A” Frame)
115/60 804,500,67x.x1 804,500,67x.x1
220/50 804,500,70x.x1 804,500,70x.x1
3D Condenser Fan Blade
All Styles FY870CW25S 800,103,37x.x2 800,103,37x.x2
4A Drain Pan Assy. w/ Fiberglass Soakers 491,000,10x.x3 805,800,71x.x1
4B Drain Pan, Plastic w/ Fingers (Not Shown) 801,804,24x.x1 801,804,24x.x1
4C Soakers, Fiberglass (14 required) 905,800,69x.x1 905,800,69x.x1
5A Ingress Guard 594,041,40x.x3 594,041,40x.x3
5B Rear Condensate Plate 801,903,52x.x1 801,903,52x.x1
6A Drain Tube 801,806,05x.x1 801,806,05x.x1
6B Drain Tube Nut 900,301,79x.x1 900,301,79x.x1
7A Drain Hose 901,900,50x.x1 901,900,50x.x1
7B Drain Hose Clamp 900,901,03x.x1 900,901,03x.x1
8 Main Wiring Harness (Detachable)
United States & Mexico 804,902,22x.x1 804,917,26x.x1
9 Power Cord (Detachable) 804,917,28x.x1 804,917,28x.x1
