PARTS LIST
NA = Not Applicable
Part numbers subject to change without notice.
77
REFRIGERATION SYSTEM
(SECTION TWO)
ITEM
DESCRIPTION
HT2 (501E)
HT3 (501E)
9 Fan Housing Assy.
Assy., Housing Fan (Wide) 609,044,80x.x1 609,044,80x.x1
10 Temperature Sensor (Board) 804,917,44x.x1 804,917,44x.x1
10A Temp Sensor Harness 804,917,41x.x1 804,917,41x.x1
10B Cover, Temp Sensor HVV 631,001,42x.x3 631,001,42x.x3
11 Condenser Fan Shroud 491,040,11x.x3 491,040,11x.x3
12 Overload – Relay Cover Assy.
Domestic 802,501,77x.x1 802,501,77x.x1
12A Relay
Domestic Models Embraco 1.351.605 802,502,13x.x1 802,502,13x.x1
12B Overload
Domestic Models 802,502,10x.x1 802,502,10x.x1
12C Cover 802,501,86x.x1 802,501,86x.x1
13 Dryer
.054 Outlet 4AXH7 802,401,29x.x1 802,401,29x.x1
14 Condenser
“B” 1/3 HP 802,600,55x.x1 802,600,55x.x1
15 Evaporator (short)
CW01655 (1/3 HP) 802,600,37x.x1 802,600,37x.x1
16 Accumulator
1/3 HP 802,400,46x.x1 802,400,46x.x1
17 Capacitor, Start
Domestic, 233-280MFD / 115V 60 Hz (FOR 1/3 HP) 802,501,21x.x1 802,501,21x.x1
17A Capacitor, End Cap Bottom Hole (Not Shown)
Domestic 802,501,18x.x1 802,501,18x.x1
17B Capacitor Assembling Bracket (Not Shown)
Domestic 802,501,87x.x1 802,501,87x.x1
18 Cover, Embraco (Not Shown)
x.x5x.x04 Short (Domestic) – 1/3 HP 802,501,86x.x1 802,501,86x.x1
x.x5x.x00 Long (220/50) – 1/3 HP 802,501,95x.x1 802,501,95x.x1
19 Top Evaporator Cover 609,050,06x.x3 609,050,51x.x3
20 Temp Control Plate NA 491,070,08x.x3
21 GE Temp Control NA 802,800,58x.x1
22 Silencer 902,100,29x.x1 902,100,29x.x1
To Next Page
