PROGRAMMING P-SERIES
Page 17 of 78
Press select button 1 to select the package type that is displayed.
If a predefined package type(1, 2, 3, 4, or 5) is selected
After the package type has been selected , “Key 1 = Prime Key 2 = Exit” will be displayed. Press
button 1 to prime the column with product or button 2 to exit without priming the column. If select
button 2 is pressed the column will be marked as jammed and will prime when the door is closed.
HA - Hold Angle - Will only be displayed if the package type selected is custom.
This allows setting the hold angle for the column selected in the column prompt. Press select
button 1 to display the current hold angle, HA ###. Press select buttons 1 & 2 simultaneously to
scroll through hold angles. Press select button 1 to select the displayed hold angle.
“Depth”(DEEP) will be displayed after the hold angle is set.
“DEEP” – Depth - Will only be displayed if the package type selected is custom.
This allows setting the product depth for the column selected in the column prompt. The current
product depth, DP # is displayed when select button 1 is pressed. Press select buttons 1 & 2
simultaneously to scroll through available product depths. Press select button 1 to select the
displayed depth.
“VA”- Vend Angle - Will only be displayed if the package type selected is custom.
This allows setting the vend angles for the column selected in the column prompt. VA# ### will
be displayed where the first # is the product number in the column and the ### is the vend angle
for that product. The user will be prompted to enter to same number of vend angles as was
entered at the “DEEP” prompt. After the last vend angle is entered the display will show “2 =
EXIT 1 = PRIME”. Press button 1 to prime the column with product or button 2 to exit without
priming the column. If select button 2 is pressed the column will be marked as jammed and will
prime when the door is closed.
“RTN” - Return
Pressing select button 1 will return to “Column” (CL)
Press and hold select buttons 1 & 2 simultaneously to move to the next item on the menu
Time
This function is used to set the year, month, day, hour/minute (military 24 hour clock), and daylight
savings time. Press select button 1 and “Year” will show on display. Press select buttons 1 and 2
simultaneously to scroll through all “Time” sub-menus.
“Year”- Year Setting (2000 to 2099)
Press select button 1 the current year setting will show on display.
Press and hold select button 1 to increment the year setting (2000 to 2099).
Release select button 1 and press and hold again will decrement the year setting.
Release the select button with the display showing the year you wish to use and display will
return to “Year”.
Press select buttons 1 & 2 simultaneously to scroll to “MTH”.
”MTH” - Month Setting (01 to 12)
Press select button 1 and the current 2-digit month setting will show on display.
Press and hold select button 1 to scroll through the month settings. (01-Jan. to 12-Dec).
Release the select button with the display showing the month you wish to use and display will
return to “MTH”.
Press select buttons 1 & 2 simultaneously to scroll to “Day”.
