GENERAL INFORMATION P-SERIES
Page 7 of 78
APPLICATION
This information applies to P-Series venders
manufactured the third quarter 2003 which have
significant differences in programming and parts
content from previous venders. To order parts or
information pertaining to this vender, please contact
Dixie Narco.
VENDER SAFETY PRECAUTIONS
Please read this manual in its entirety. This service
information is intended for use by a qualified service
technician, who is familiar with proper and safe
procedures to be followed when repairing, replacing,
or adjusting any Dixie-Narco vender components.
All repairs should be performed by a qualified
service technician who is equipped with the proper
tools and replacement components, using genuine
Dixie-Narco factory parts.
REPAIRS AND/OR SERVICING
ATTEMPTED BY UNINFORMED
PERSONS CAN RESULT IN
HAZARDS DEVELOPING DUE TO
IMPROPER ASSEMBLY OR
ADJUSTMENTS WHILE
PERFORMING SUCH REPAIRS.
PERSONS NOT HAVING A PROPER
BACKGROUND MAY SUBJECT
THEMSELVES TO THE RISK OF
INJURY OR ELECTRICAL SHOCK
WHICH CAN BE SERIOUS OR EVEN
FATAL.
PRODUCT IDENTIFICATION
First production of P-Series August 2003
The production date of Dixie-Narco products is
determined by the date code incorporated in the
serial number.
The vender serial number takes the form yyyyzz-
xxxx.The last 4 digits (xxxx) identify the specific
vender. The first 4 digits (yyyy) identify the
manufacturing run that the vender was built in. The
two alpha characters (zz) identify the quarter and the
year the vender was built. The first alpha-character
identifies the quarter.
A = 1st quarter
B = 2nd quarter
C = 3rd quarter
D = 4th quarter
The second alpha-character identifies the year:
B = 2003
C = 2004
D = 2005
PHYSICAL CHARACTERISTICS
552P 756P
HEIGHT
72” 72”
WIDTH
28” 36”
DEPTH
33.5” 33.5”
DEPTH WITH
VALIDATOR
N/A N/A
SHIPPING WEIGHT
600 lbs. 788 lbs.
Loaded Weight 4 Deep
Cans
1134 lbs TBD
Model # of
Selections
# of
Wide
Columns
# of
Narrow
Columns
552P 8 2 4
756P 12 3 5
RECEIVING INSPECTION
Upon receipt, inspect the vender for any shipping
damage. If there is any damage have the driver
note the damage on the bill of lading and notify
Dixie-Narco.
Although the terms of sale are FOB shipping point,
which requires the consignee to originate shipping
damage claims, Dixie-Narco will gladly help if you
must file a claim.
