PROGRAMMING P-SERIES
Page 16 of 78
MV – MULTI VEND
This function, when turned on, allows credit to be retained after a vend so the customer can vend from
another selection. (i.e..50 vend price, put in $1.00, push a select button and vends, .50 still shows on the
display, push a second select button and vends). Credit is cancelled after 5 minutes of inactivity. There
is unlimited acceptance. If a customer wants their credit (money) back, the coin return lever must be
pressed. To show the current “Multi Vend” condition, press select button 1 and the display will show the
current setting. Press and hold button 1 to toggle “Multi Vend” between “On” and “Off”.
Press and hold select buttons 1 & 2 simultaneously to move to “Return”.
RTN - RETURN
Press and hold button 1 to return to “Cash”.
USER
This function is used to configure the vender to operate in a fashion best suited for the vender location. To move
to “Diagnostics”(DIAG), press & hold select buttons 1 & 2 simultaneously, to enter the User Menu sub-menus
press select button1. The following are sub-menus of the User Menu: Space To Sales(STS), Column(CL), Time,
Language(LANG), Electronic Counter(ECNT), Limited Access(LIM), Secondary Price(SEC), Environmental
Controls(ECTL), Light(LT), Refrigeration(RFRG), Free Vend(FREE), Override(OVER), Sales Message(SSM),
Recharge(R-CH), and Return(RTN). The “Column” sub-menu prompt will only be available in machines with DC
motors.
STS – SPACE TO SALES
To view the space to sales condition, press select button 1 and display will show (SEL 1) “Selection 1”.
Alternating with columns assigned to that select button. Press select buttons 1 & 2 simultaneously to
scroll through the available select buttons to view columns assigned and “Return”.
To change space to sales
Press select button 1 at the “SEL #” prompt (CL## #)(column edit routine) will be displayed,
where the ## is the column to be added or deleted to the select button and the third # is “0” for
not assigned or “1” for assigned to that selection. Press select button 1 with “CL ## #” on the
display to toggle between “CL ## 0” and “CL ## 1”. With the setting you wish to use showing on
the display, press select buttons 1 & 2 to scroll to next columns to add/delete columns. Press
select button 1 at the “Return” prompt when selecting columns to enable, will return to “SEL #”.
Press select button 1 at the “RTN” prompt when choosing what selection to set for Space to
Sales, will return to “STS”.
Note: You must be in the “Selection” prompt to get to the “Return” mode that goes back to “Space
To Sales”.
Press & hold select buttons 1 & 2 simultaneously to move to the next item on the menu.
CL- Column This prompt only appears on machines with DC motors.
Select this prompt to set column depth, package type and vend angles if the package type is custom. This
will scroll through the list of columns 1--- 9, “ALL” or “Return”(RTN) to select what column(s) will have its
settings changed. Pressing button 1 will display “Column # ”(CL #) where # represents the column
number.
Pressing select buttons 1 & 2 simultaneously will scroll through the columns.
Press select button 1 to scroll to “Package”
“Pack” Package - is the next prompt. Press select buttons 1 & 2 simultaneously after entry into
this sub-menu will toggle between “Pack” and “RTN”. Pressing select button 1 when “Pack” is
displayed allows setting the package type for the column selected in the column prompt. Pressing
select button 1 will show current package setting. (i.e.1, 2, 3, …, “CUST” (CUSTOM), and “RTN”
(RETURN). Press select buttons 1 & 2 simultaneously to scroll through the package settings.
