EVAPORATOR FAN ASSEMBLY
ITEM DESCRIPTION DN552P DN756P
1 Harness, Evaporator 3 Fan 804,921,73x.x1 Same
2 Evaporator Fan Motor Assy. 115V/60Hz 640,040,30x.x3 Same
Evaporator Fan Motor Assy. 220V 639,040,60x.x3 TBD
3 Bracket, Evaporator Fan Motor 640,040,06x.x3 Same
4A Bracket, Evaporator Fan Panel Left Hand 640,040,08x.x3 Same
4B Bracket, Evaporator Fan Panel Right Hand 640,040,07x.x3 Same
5 Sub Assembly Evaporator Fan Shroud – 3 640,040,20x.x3 NA
Sub Assembly Evaporator Fan Shroud – 4 NA 639,040,30x.x3
6 Screw, Phil Pan 8 - 18 x 1/2" 900,301,50x.x1 Same
7 Hex Nut #10 - 32 900,800,65x.x1 Same
8 Tie, 5.5 “ Hand 901,901,06x.x1 Same
9 Bushing, ¾” split Heyco 901,902,17x.x1 Same
10 Screw, Sems Phil Pan 8 – 32 x 3/8 800,303,42x.x1 Same
11 Strip, Poly Foam 24.5” (under chute) “Air Stop” (Not Shown) 803,301,38x.x1 Same
21 Fan Bracket, Evaporator 640,040,06x.x3 Same
22 Evaporator Fan Motor 115V 3000 RPM 0.5 Amp 804,501,25x.x1 Same
Evaporator Fan Motor 220V 804,501,38x.x1 Same
23 Blade, Fan 6.0” CCW (4 blade plastic) 801,818,88x.x1 Same
24 Speed Nut (Evaporator fan) (Not Shown) 900,800,85x.x1 Same
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable
