Dixie Narco P Series - Page 56

PARTS LIST P-SERIES
Page 56 of 78
SELECT PANEL
ITEM PART DESCRIPTION
DN552P DN756P
1 Select Panel Assembly, 7 Select
594,054,30x.x3 NA
Select Panel Assembly, 8 Select
NA 594,054,20x.x3
1a Weld assembly Select Panel, 7 Select
594,055,00x.x3 NA
Weld assembly Select Panel, 8 Select
NA 594,054,50x.x3
2 Switch, Membrane 7 select
804,913,01x.x1 NA
Switch, Membrane 8 select
NA 804,912,86x.x1
3 Assembly, Chassis & Stud
594,054,70x.x3 Same
4 Select Button (Membrane)
801,809,24x.x1
Same
5 Keypad, 5 Position
801,809,26x.x1
Same
6 Harness, Membrane “From Board to Membrane”
804,921,13x.x1
Same
7 Standoff, .187 x .312 x .625
901,001,44x.x1
Same
8 Hex Nut # 8 -32
900,800,50x.x1
Same
2
1
4
5
3
Part numbers & descriptions are subject to change with out notice.
N
A = Not a
pp
licable
