PARTS LIST P-SERIES
Page 74 of 78
REFRIGERATION SYSTEM
(SECTION ONE)
ITEM DESCRIPTION
DN552P DN756P
Model 3001C-E Kit 115V/60Hz 609,047,10x.x4 Same
Model 3021-E Refrigeration Unit 220V 639,040,50x.x3 Same
1 Base Plate 639,040,02x.x3 Same
2 Condenser, 1.33 FPI 802,600,69x.x1 Same
3 Assembly, Heat Exchanger 640,040,00x.x3 Same
4 Fan Blade, Condenser (FV900CW30S) 801,306,65x.x1 Same
5 Assembly, Condenser Fan Motor 115/60 (9W CW) 804,501,22x.x1 Same
Assembly, Condenser Fan Motor Export 804,501,37x.x1 Same
6 Tube Discharge 640,040,04x.x3 Same
7 Shroud, Condenser 640,040,02x.x3 Same
8 Label, Name Plate 115/60 803,872,04x.x1 Same
9 Tube, Evaporator – Accumulator Adapter 491,040,19x.x3 Same
10 Accumulator 802,400,46x.x1 Same
11 Dryer,.054 Extended outlet, 134A 802,401,29x.x1 Same
12 Capacitor End Cap, Bottom Hole 802,501,18x.x1 Same
13 Compressor E FFI12HBX 115/60 802,501,74x.x1 Same
Compressor E FFI12HBK 220/50 802,502,17x.x1 Same
14 Cover, Embraco (1.355.504 short) 802,501,86x.x1 Same
15 Bracket, Capacitor 802,501,87x.x1 Same
16 Overload, MRT 22AFZ-5598 802,502,10x.x1 Same
Overload, MRP 40APN-5598 (Export) 802,502,19x.x1 Same
17 Relay, 1.351.605 802,502,13x.x1 Same
Relay, 21.351.6035 (Export) 802,502,18x.x1 Same
18 Capacitor, Start 233-280 MFD/165V 802,502,21x.x1 Same
19 Evaporator, Short 802,600,37x.x1 Same
20 Tube, ¼ OD x .028 W, Copper 803,000,39x.x1 Same
21 Screw, Brass 6-32x1/4 900,201,44x.x1 Same
22 Screw, 8-32x3/8 900,301,56x.x1 Same
23 Screw, Phil Flat Head 10-32x1/2 900,301,94x.x1 Same
24 Nut, Speed 900,800,85x.x1 Same
25 Clip, Spring 900,901,88x.x1 Same
26 Plug, Compressor Grommett 901,803,91x.x1 Same
27 Grommet, Compressor 902,000,57x.x1 Same
28 Silencer 902,100,29x.x3 Same
29 Label, 134a Recoverable Substance 903,833,54x.x1 Same
30 Terminal 904,601,36x.x1 Same
31 Lead, Compressor (harness) 904,900,61x.x1 Same
Lead, Compressor (harness) - Europe 804,905,32x.x1 Same
32 Drain Pan Assembly with Fiberglass Soakers (Not Shown) 805,800,71x.x1 Same
33 Soakers, Fiberglass (14 required) (Not Shown) 905,800,69x.x1 Same
34 Ingress Guard 000455 639,020,01x.x3
35 Drain Tube 801,806,05x.x1 Same
36 Drain Tube Nut 900,301,79x.x1 Same
37 Drain Hose 901,900,50x.x1 Same
38 Drain Hose Clamp 900,901,03x.x1 Same
39 Power Cord (Detachable) 804,917,28x.x1 Same
40 Temperature Sensor Encapsulated (Not Shown) 000115 Same
41 Temp Sensor Jumper 804,921,63x.x1 Same
Part numbers & descriptions are subject to change with out notice.
NA = Not applicable
