dji AVATA User Manual

DJI Avata
User Manual
9
© 2022 DJI All Rights Reserved.
56 - 72 mm
-0.8 D
- +2.0D
56 - 72 mm
-0.8 D
- +2.0D
56 - 72 mm
-0.8 D
- +2.0D
56 - 72 mm
-0.8 D
- +2.0D
5. Wear the goggles and adjust the headband until the goggles t comfortably.
6. Use the IPD (Interpupillary Distance) Slider / Diopter Adjustment Knob (hereinafter referred to as "knob") to
adjust the distances between the lenses and the diopter to get a clear view.
a. Rotate both the knobs in the direction as shown to unlock them. Once unlocked, the knobs will pop out.
b. Toggle the knobs left and right to adjust the distance between the lenses until the images are
properly aligned.
c. Slowly rotate the knobs to adjust the diopter. The supported adjustment range is from -8.0 D to
+2.0 D.
56 - 72 mm
-0.8 D
- +2.0D
d. After you get a clear view, press the knobs in and rotate them in the direction as shown to lock in
the lenses’ position and the diopter.

dji AVATA Specifications

General

Type	Quadcopter
Certification	CE
Product color	Black, Grey
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	- m/s
Number of rotors	4 rotors
Maximum weight capacity	- kg
Maximum operating distance	10000 m
Number of propeller blades	5
Megapixel	- MP
Sensor type	CMOS
Maximum frame rate	100 fps
Optical sensor size	1/1.7 \
Supported video modes	1080p
Video formats supported	H.265
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	50 Mbit/s
Memory card slot(s)	-
Moving control functions	Backward, Downward, Flying sideways, Forward, Turn left, Turn right, Upward
Operating time	120 min
Number of batteries supported	1

Weight and Dimensions

Weight	1000 g
