dji GOGGLES 3 User Manual

DJI Goggles 3 User Manual
©
2024 DJI All Rights Reserved.
11
3. Slowly rotate the knobs to adjust the diopters. The supported adjustment range is from
-6.0D to +2.0D.
+2.0D ~ -6.0D +2.0D ~ -6.0D
• The goggles do not support astigmatism correction. If you require astigmatism
correction or if the diopters of the goggles are unsuitable, you can purchase additional
lenses and use the corrective lenses frames provided to install them on the goggles.
Refer to “Using the Corrective Lenses” for more information.
• When adjusting the diopters for the rst time, you are advised to adjust to a degree
that is slightly lower than the strength of your actual eyeglasses. Give your eyes
enough time to adapt, then adjust the diopters again until you get a clear view. Do not
use a diopter value higher than your actual eyeglass power to avoid eyestrain.
4. After you get a clear view, press the knobs in and rotate them in the direction as shown to
lock in the lenses’ position of the lenses and the diopters.

dji GOGGLES 3 Specifications

General

Field of View	51°
Interpupillary Distance Range	56-72 mm
Video Recording Max Bitrate	50 Mbps
Resolution	1920x1080 per eye
Refresh Rate	100Hz
Screen Size (Single Screen)	0.49 inches
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Wi-Fi Protocol	802.11 b/g/n/ac
Wi-Fi Operating Frequency	2.4GHz, 5.8GHz
Bluetooth Transmitter Power (EIRP)	<10dBm
Video Recording Format	MOV (H.264)
Supported Video and Audio Playback Formats	MP4, MOV (H.264/H.265)
Operating Temperature	-10°C to 40°C
Power Input	USB-C, 5V/2A
Supported SD Cards	microSD
Charging Time	2 hours
Compatibility	DJI Air 3
Connectivity	USB-C
Wi-Fi Transmitter Power (EIRP)	2.4GHz: <20dBm; 5.8GHz: <14dBm
Latency	With DJI Avata 2: 24 ms; With DJI Air 3: 24 ms; With DJI Mini 4 Pro: 24 ms
