DJI Goggles 3 User Manual

The table below shows the battery level during charging:

LED1 LED2 LED3 LED4

Battery Level

1%-50%

51%-75%

76%-99%

100%

• USB-C port spec: USB 2.0 (480 Mbps). The maximum input power is 9V/3A.

Wearing the Goggles

• The battery wires are embedded in the headband. DO NOT pull the headband with

force to avoid damaging the wires.

• Fold the antennas to avoid damage when the goggles are not in use.

• DO NOT tear or scratch the foam padding, the additional forehead pad, and the soft

side of the battery compartment with sharp objects.

• DO NOT bend the additional forehead pad with force.

• DO NOT rotate the headband adjustment knob or the diopter adjustment knob with

force to avoid component damage.

1. Unfold the antennas.

2. Adjust the forehead pad downward to the lowest position.

Other manuals for dji GOGGLES 3

Need help?

Do you have a question about the dji GOGGLES 3 and is the answer not in the manual?

General

Field of View	51°
Interpupillary Distance Range	56-72 mm
Video Recording Max Bitrate	50 Mbps
Resolution	1920x1080 per eye
Refresh Rate	100Hz
Screen Size (Single Screen)	0.49 inches
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Wi-Fi Protocol	802.11 b/g/n/ac
Wi-Fi Operating Frequency	2.4GHz, 5.8GHz
Bluetooth Transmitter Power (EIRP)	<10dBm
Video Recording Format	MOV (H.264)
Supported Video and Audio Playback Formats	MP4, MOV (H.264/H.265)
Operating Temperature	-10°C to 40°C
Power Input	USB-C, 5V/2A
Supported SD Cards	microSD
Charging Time	2 hours
Compatibility	DJI Air 3
Connectivity	USB-C
Wi-Fi Transmitter Power (EIRP)	2.4GHz: <20dBm; 5.8GHz: <14dBm
Latency	With DJI Avata 2: 24 ms; With DJI Air 3: 24 ms; With DJI Mini 4 Pro: 24 ms
