DJI Goggles 3 User Manual

• After installing the -2.0D Corrective Lenses, the diopter value displayed on the screen

is not the actual diopter value. The actual diopter value is the sum of the on-screen

value and -2.0D.

Purchasing and Installing Your Own Corrective Lenses

If you require astigmatism correction or the diopters of the goggles cannot meet your needs,

you can purchase suitable lenses and use the corrective lens frames to install them.

• When purchasing lenses, bring the full set of -2.0D Corrective Lenses (a pair with the

frames) to a professional optician to ensure that the shape, size, astigmatism axis,

and edge thickness (< 1.8 mm) of the lenses meet the installation requirements of the

corrective lens frames.

1. Push and remove the -2.0D lens from the frame. Turn the frame over.

4. Adjust the diopters of the goggles according to your needs and lock the knobs.

2. Identify the shortest cut edge (c) in the frame.

Other manuals for dji GOGGLES 3

Need help?

Do you have a question about the dji GOGGLES 3 and is the answer not in the manual?

General

Field of View	51°
Interpupillary Distance Range	56-72 mm
Video Recording Max Bitrate	50 Mbps
Resolution	1920x1080 per eye
Refresh Rate	100Hz
Screen Size (Single Screen)	0.49 inches
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Wi-Fi Protocol	802.11 b/g/n/ac
Wi-Fi Operating Frequency	2.4GHz, 5.8GHz
Bluetooth Transmitter Power (EIRP)	<10dBm
Video Recording Format	MOV (H.264)
Supported Video and Audio Playback Formats	MP4, MOV (H.264/H.265)
Operating Temperature	-10°C to 40°C
Power Input	USB-C, 5V/2A
Supported SD Cards	microSD
Charging Time	2 hours
Compatibility	DJI Air 3
Connectivity	USB-C
Wi-Fi Transmitter Power (EIRP)	2.4GHz: <20dBm; 5.8GHz: <14dBm
Latency	With DJI Avata 2: 24 ms; With DJI Air 3: 24 ms; With DJI Mini 4 Pro: 24 ms
