dji GOGGLES 3 User Manual

DJI Goggles 3 User Manual
©
2024 DJI All Rights Reserved.
17
• If you are using DJI RC 2 or DJI RC-N2, make sure that the remote controller and
aircraft are linked, then link the aircraft with the goggles.
• The aircraft can be controlled with only one remote control device during flight. If
the aircraft has been linked with multiple remote control devices, turn o the other
remote control devices before linking.
a. Press and hold the power button on the goggles until the goggles start to beep
continuously and the battery level LEDs start to blink in sequence.
b. Press and hold the power button on the remote control device until it starts to beep
continuously and the battery level LEDs start to blink in sequence.
c. Once linking is completed, the goggles and remote control device stop beeping and both
the battery level LEDs turn solid and display the battery level.
5s
5s
5s
c. Once linking is completed, the battery level LEDs of the aircraft turn solid and display
the battery level, the goggles stop beeping, and image transmission can be displayed
normally.
2. Linking the goggles and remote control device:

dji GOGGLES 3 Specifications

General

Field of View	51°
Interpupillary Distance Range	56-72 mm
Video Recording Max Bitrate	50 Mbps
Resolution	1920x1080 per eye
Refresh Rate	100Hz
Screen Size (Single Screen)	0.49 inches
Operating Frequency	2.400-2.4835 GHz; 5.725-5.850 GHz
Wi-Fi Protocol	802.11 b/g/n/ac
Wi-Fi Operating Frequency	2.4GHz, 5.8GHz
Bluetooth Transmitter Power (EIRP)	<10dBm
Video Recording Format	MOV (H.264)
Supported Video and Audio Playback Formats	MP4, MOV (H.264/H.265)
Operating Temperature	-10°C to 40°C
Power Input	USB-C, 5V/2A
Supported SD Cards	microSD
Charging Time	2 hours
Compatibility	DJI Air 3
Connectivity	USB-C
Wi-Fi Transmitter Power (EIRP)	2.4GHz: <20dBm; 5.8GHz: <14dBm
Latency	With DJI Avata 2: 24 ms; With DJI Air 3: 24 ms; With DJI Mini 4 Pro: 24 ms
