dji MAVIC 2 ENTERPRISE Advanced User Manual

MAVIC 2 ENTERPRISE Advanced
User Manual
©
2021 DJI All Rights Reserved.
47
IR View
4.0X
4.0X
29ºC 29ºC
502 502
D
D
m
m
120 120
H
H
m
m
16.0 16.0
H.S
H.S
m/s
m/s
24.0 24.0
V.S
V.S
m/s
m/s
123456 123456
123456 123456
+ 147.498992, - 122.274800
2021-2-5 13:14
147.498992,-122.274800
FFC
In-Flight
（
GPS
）
19:29
GPS
12
2.4G
61%
MENU
12
12
IR 1x
SPLIT
VISIBLE
1X
IR
8 X
2 X
4 X
VISIBLE
1. Palette
: Mavic 2 Enterprise Advanced oers a variety of palette options. Distinct colors are used to
show temperature dierences in the thermal image, which are related to grayscale intensity. The
temperature range of the image is mapped to 256 colors and displayed in 8-bit JPEG or MP4
format. The following table shows all palette options.
2. FFC Calibration
Tap this button to enable FCC calibration in IR Mode. FCC calibration is used to optimize image
quality, during which the screen may freeze momentarily.
3. Temperature Measurement
Tap to enable the temperature measurement. Spot Meter and Area Measurement are available in
IR mode. Close Area Measurement to exit temperature measurement.
a) Spot Meter: the temperature of any position in an image can be measured. Refer to the
Specications for more information about measurement accuracy.
1 2
34
White Hot
Fulgurite
Iron Red
Hot Iron
Medical
Arctic
Rainbow 1
Rainbow 2
Tint
Black Hot

dji MAVIC 2 ENTERPRISE Advanced Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-

Weight and Dimensions

Depth	455 mm
Width	290 mm
Height	225 mm
Weight	1710 g
Battery weight	297 g
Transmitter weight	630 g
Takeoff weight (max)	1100 g
