dji Mavic 3 User Manual

DJI Mavic 3 User Manual
10
©
2021 DJI All Rights Reserved.
1. Antennas
Relay aircraft control and video wireless
signals.
2. Back Button
Press once to return to the previous screen.
Press twice to return to the home screen.
3. Control Sticks
Use the control sticks to control the aircraft
movements. Set the ight control mode in DJI
Fly. The control sticks are removable and easy
to store.
4. Return to Home (RTH) Button
Press and hold to initiate RTH. Press again to
cancel RTH.
5. Flight Pause Button
Press once to make the aircraft brake and
hover in place (only when GNSS or Vision
Systems are available).
6. Flight Mode Switch
Switch between Cine, Normal, and Sport
mode.
7. 5D Button
View the 5D Button features in DJI Fly by
entering Camera View, Settings, and then
Control.
8. Power Button
Press once to check the current battery level.
Press and then press and hold to power the
remote controller on or o. When the remote
controller is powered on, press once to turn
the touchscreen on or o.
1
2
3
4
5
10
11
12
13
6
7
8
9
DJI RC Pro
14 19
18
16 17
15
9. Conrm Button
Press once to conrm a selection. The button
does not have a function when using DJI Fly.
10. Touchscreen
Touch the screen to operate the remote
controller. Note that the touchscreen is not
waterproof. Operate with caution.
11. microSD Card Slot
Use to insert a microSD card.
12. USB-C port
For charging.
13. Mini HDMI Port
For video output.
14. Gimbal Dial
Controls the tilt of the camera.
15. Record Button
Press once to start or stop recording.
16. Status LED
Indicates the status of remote controller.
17. Battery Level LEDs
Displays the current battery level of the
remote controller.
18. Focus/Shutter Button
Press halfway down on the button to auto
focus and press all the way down to take a
photo.
19. Camera Control Dial
For zoom control.

dji Mavic 3 Specifications

General

Type	Quadcopter
Product color	Black
Maximum speed	19 m/s
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	40 min
Maximum flight time	46 min
Maximum ascent speed	8 m/s
Maximum descent speed	6 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	30000 m
Maximum pitch angular velocity	200 °/sec
USB ports quantity	2
Operating frequency	2400000 MHz
Battery voltage	15.4 V
Battery capacity	5000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG
Video formats supported	H.264, H.265
Maximum image resolution	5280 x 3956 pixels
Maximum video resolution	5120 x 2700 pixels
Field of view (FOV) angle	84 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	-
Moving control functions	Backward, Downward, Forward, Upward

Weight and Dimensions

Depth	221 mm
Width	96.3 mm
Height	90.3 mm
Weight	895 g
Battery weight	335.5 g
