dji Mavic 3 User Manual

DJI Mavic 3 User Manual
33
©
2021 DJI All Rights Reserved.
Controlling the Aircraft
Three preprogrammed modes (Mode 1, Mode 2, and Mode 3) are available and custom modes can be
congured in DJI Fly. The default mode is Mode 2.
Right StickLeft Stick
Turn RightTurn Left
Up
Down
RightLeft
Up
Down
Turn RightTurn Left
RightLeft
Forward
Backward
Left Stick Right Stick
Forward
Backward
Right Stick
Up
Down
Forward
Backward
Left Stick
Turn RightTurn Left
RightLeft
Mode 2
Mode 1
Mode 3

dji Mavic 3 Specifications

General

Type	Quadcopter
Product color	Black
Maximum speed	19 m/s
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	40 min
Maximum flight time	46 min
Maximum ascent speed	8 m/s
Maximum descent speed	6 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	30000 m
Maximum pitch angular velocity	200 °/sec
USB ports quantity	2
Operating frequency	2400000 MHz
Battery voltage	15.4 V
Battery capacity	5000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG
Video formats supported	H.264, H.265
Maximum image resolution	5280 x 3956 pixels
Maximum video resolution	5120 x 2700 pixels
Field of view (FOV) angle	84 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	-
Moving control functions	Backward, Downward, Forward, Upward

Weight and Dimensions

Depth	221 mm
Width	96.3 mm
Height	90.3 mm
Weight	895 g
Battery weight	335.5 g
