dji Mavic 3 User Manual

DJI Mavic 3 User Manual
59
©
2021 DJI All Rights Reserved.
Forward Vision System Precision Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Eective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal), 103° (vertical)
Backward Vision System Precision Measurement Range: 0.5-16 m
Eective Sensing Speed: ≤12 m/s
FOV: 90° (horizontal), 103° (vertical)
Lateral Vision System Precision Measurement Range: 0.5-25 m
Eective Sensing Speed: ≤15 m/s
FOV: 90° (horizontal), 85° (vertical)
Upward Vision System Precision Measurement Range: 0.2-10 m
Eective Sensing Speed: ≤6 m/s
FOV: 100° (front and back), 90° (left and right)
Downward Vision System Precision Measurement Range: 0.3-18 m
Eective Sensing Speed: ≤6 m/s
FOV: 130° (front and back), 160° (left and right)
Operating Environment Forward, Lateral, Upward, Backward: Discernible surfaces, adequate
lighting of lux >15
Downward: Non-reective, discernible surfaces with diuse reectivity
of >20%, such as walls, trees, people; Adequate lighting of lux >15
Surface with a clear pattern
Transmission
Video Transmission System O3+
Live View Quality Remote Controller: 1080p@30fps/1080p@60fps
Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz
Max Transmission Distance
(unobstructed, free of interference)
15 km (FCC), 8 km (CE/SRRC/MIC)
Max Download Speed SDR: 5.5 MB/s (with RC-N1)
15 MB/s (with DJI RC Pro)
Latency (depending on environment
and mobile device)
130 ms (with RC-N1)
120 ms (with DJI RC Pro)
Antennas 4 antennas, 2T4R
Transmitter Power (EIRP) 2.4 GHz: <33 dBm, FCC, <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
Intelligent Flight Battery
Capacity 5000 mAh
Standard Voltage 15.4 V
Max Charging Voltage 17.6 V
Battery Type LiPo 4S
Energy 77 Wh
Weight 335.5 g
Charging Temperature 5° to 40° C (41° to 104° F)
Battery Charger
Input 100-240 V AC (47-63 Hz) 2.0 A
Output USB-C: 5.0 V 5.0 A/9.0 5.0 A/12.0 V 5.0 A/15.0 V 4.3 A/
20.0 V 3.25 A/5.0~20.0 V 3.25 A USB-A: 5 V 2 A
Rated Power 65 W

dji Mavic 3 Specifications

General

Type	Quadcopter
Product color	Black
Maximum speed	19 m/s
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	40 min
Maximum flight time	46 min
Maximum ascent speed	8 m/s
Maximum descent speed	6 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	30000 m
Maximum pitch angular velocity	200 °/sec
USB ports quantity	2
Operating frequency	2400000 MHz
Battery voltage	15.4 V
Battery capacity	5000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG
Video formats supported	H.264, H.265
Maximum image resolution	5280 x 3956 pixels
Maximum video resolution	5120 x 2700 pixels
Field of view (FOV) angle	84 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	-
Moving control functions	Backward, Downward, Forward, Upward

Weight and Dimensions

Depth	221 mm
Width	96.3 mm
Height	90.3 mm
Weight	895 g
Battery weight	335.5 g
