dji PHANTOM 2 User Manual

©2013-2014 DJI. All Rights Reserved.28 |
Max
Height
Max
Radius
Home Point
The height of
aircraft when it
is powered on
Figure 6-3 Figure 6-4
Ready to Fly
Limits
Ground Station
Rear LED flight indicator
Max Height
The flight height is restricted to fly
under the max height.
Warning: Height limit
reached.
None.
Max Radius
The flight distance is restricted to fly
within the max radius.
Warning: Distance limit
reached.
Rapid red flashings
when close to the Max radius limit.
Ready to Fly(non-GPS)
Flight Limits
Ground Station
Rear LED flight indicator
Max Height
The flight height is restricted to fly
under the minor height between the
Max height and 120m.
Warning: Height limit reached.
None.
Max Radius
Not limited, no warnings or LED indicators.
(1) If the aircraft flies out of the limits, you can still control your aircraft except to fly it further away.
(2) If the aircraft is flying out of the max radius in Ready to Fly (non-GPS) status, it will fly back
within the limits range automatically if 6 or more GPS satellites have been found.
6.7 Flight Limits of Special Areas
Special areas include airports worldwide. All special areas are listed on the DJI official website. Please refer to
http://www.dji.com/fly-safe/category-mc for details. These areas have been divided into category A and category B.

dji PHANTOM 2 Specifications

General

Frequency band	2.4 GHz
Maximum operating distance	1000 m
Battery capacity	5200 mAh

Weight and Dimensions

Weight	1000 g
