dji PHANTOM 2 User Manual

©2013-2014 DJI. All Rights Reserved.35 |
8 Appendix
8.1 Specifications
Aircraft
Operating environment temperature
-10℃ to 50℃
Power consumption
5.6W
Supported Battery
DJI Intelligent battery
Weight (including the battery)
1000g
Take-off Weight
≤1300g
Hovering Accuracy (Ready to Fly)
Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity
200°/s
Max Tilt Angle
35°
Max Ascent / Descent Speed
Ascent: 6m/s; Descent: 2m/s
Max Flight Speed
15m/s (Not Recommended)
Wheelbase
350mm
2.4GHz Remote Control
Operating Frequency
2.4GHz ISM
Communication Distance (open area)
1000m
Receiver Sensitivity (1%PER)
-97dBm
Working Current/Voltage
120 mA@3.7V
Built-in LiPo Battery Working Current/Capacity
3.7V, 2000mAh
DJI Intelligent Battery
Type
3S LiPo Battery
Capacity
5200mAh, 11.1V
Charging Environment Range
0℃ to 40℃
Discharging Environment Range
-20℃ to 50℃
8.2 LED Flight Indicators Description
Aircraft in Normal status
Descriptions
Power On Self-Test
Warming Up & Aircraft cannot take off during warming up
Ready to Fly
Ready to Fly (non-GPS)
Aircraft in abnormal status
Warnings and errors
Remote Control Signal Lost
1
st
Level Low Battery Capacity Warning

dji PHANTOM 2 Specifications

General

Frequency band	2.4 GHz
Maximum operating distance	1000 m
Battery capacity	5200 mAh

Weight and Dimensions

Weight	1000 g
