1. Turn off the remote control and find the Micro-USB port on the bottom of it.
2. Start up the PC, power on the remote control, and then connect the remote control to the PC with a
Micro-USB cable. DO NOT disconnect until the configuration is finished.
3. Run the PHANTOM RC Assistant and wait for the remote control to connect to the Assistant. Observe the
indicators on the bottom left of the screen. When connected successfully, the connection indicator is
and communication indicator is blinking .
4. Finish configuration in the [Main] page.
5. Finish upgrade in the [Info] page if necessary.
DT7调参软件
Main Page of the 2.4GHz Remote Control
Language swap
Main page
Connection indicator
Communication indicator
Firmware upgrade
Account, software
version
*This image is for
reference only. Please
refer to the actual
user interface.
