Spark
User Manual
Aircraft Status Indicators
Spark has Front LEDs and Aircraft Status Indicators. The positions of these LEDs are shown in the gure
below:
The Front LEDs show the orientation of the aircraft and the status of some functions (please refer
to the Gesture Mode “Feature Descriptions” section for more details). The Front LEDs glow solid
red when the aircraft is turned on to indicate the front or nose of the aircraft.
The Aircraft Status Indicators communicate the system status of the ight controller. Refer to the
table below for more information about the Aircraft Status Indicators.
Aircraft Status Indicator Description
Normal
Alternating red, green and yellow ashes Turning On and Self Diagnostic Testing
Alternate yellow and green ashing Warming Up
Slow green ashing P Mode with GPS
×2 Two green ashes P Mode with Vision System
Slow yellow ashing No GPS and Vision System
Fast green ashing Braking
Warning
Fast yellow ashing
Remote Controller Signal Lost
Slow red ashing Low Battery Warning
Fast red ashing Critical Low Battery Warning
Red ashing IMU Error
— Solid Red Critical Error
Fast alternating red and yellow ashing Compass Calibration Required
Front LEDs
Aircraft Status Indicators

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
