DJI GO 4 App
Use this app to control the gimbal, camera, and other aircraft functions. The app features Equipment,
Editor, SkyPixel and Me sections, which are used for conguring your aircraft, editing and sharing your
photos and videos with others.
Equipment
Enter Camera View by tapping the “GO FLY” icon on the Equipment page when your mobile device
is connected to the aircraft.
Camera View
S 1.1D 9.6
H 9.6
61%
P-GPS
12
09:29
1080P/30
2.4G
In flight (GPS)
14
15
16
17
18
19
13
12
20
21
22
10
11
8 97654321
1. System Status
In ight (GPS)
: This icon indicates aircraft ight status and displays various warning messages.
2. Obstacles Detection Status
: Red bars are displayed when obstacles are close to the aircraft. Orange bars are
displayed when obstacles are in detection range.
3. Battery Level Indicator
: The battery level indicator provides a dynamic display of the battery level. The colored
zones on the battery level indicator represent the power levels needed to carry out different functions.
4. Flight Mode
: The text next to this icon indicates the current ight mode.
Tap to congure the MC (Main Controller) Settings. These settings allow you to modify ight limits and
set gain values.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
