dji SPARK User Manual

©
2017 DJI All Rights Reserved.
31
Spark User Manual
Camera
Prole
The onboard camera uses its 1/2.3 inch CMOS sensor to capture video up to 1080p at 30 fps and 12
megapixel stills. You can record video in either MOV or MP4 formats. Available picture shooting modes
include Single Shot, Burst, Interval, Panorama, and ShallowFocus. A live preview of what the camera sees
can be monitored on a connected mobile device via the DJI GO 4 app.
Camera Micro SD Card Slot
To store your photos and videos, insert the Micro SD card into the slot, as shown below, before turning on
the aircraft. Spark supports Micro SD cards up to 64 GB. A UHS-1 Micro SD card is recommended due
to their fast read and write speeds for high-resolution video recording.
Do not remove the Micro SD card from the aircraft when it is powerd on.
To ensure the stability of the camera system, single video recordings are capped at 30 minutes.
Only Micro SD cards less than or equal to 32 GB can be used on Mac computers due to
system limitations.
Capture footage can be saved to the mobile device if there is no SD card or SD card storage is
full. Note that the resolution of photos is 1024×768 and videos 1280×720.
Camera Data Port
Turn on Spark and connect a USB cable to the Micro USB Port to download photos and videos to your
computer.
The aircraft must be turned on before attempting to access les on the Micro SD card.
Controlling the Aircraft with a Mobile Device
You can connect a mobile device via Wi-Fi to control the aircraft with DJI GO 4. Follow the instructions
below to learn how.
1. Power on the aircraft.
2. Turn on your mobile device's Wi-Fi, select Spark’s network, and enter the Wi-Fi password.
3. Launch DJI GO 4. Tap “GO FLY” to enter camera view.
4. Tap the icon to take off automatically. Put both your thumbs on screen and use virtual joysticks to
maneuver the aircraft.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
