dji SPARK User Manual

©
2017 DJI All Rights Reserved.
11
Spark User Manual
3D Sensing and Vision System
Spark is equipped with a 3D Sensing System
1
, consisting of a 3D infrared module at the front of the
aircraft, which scan for obstacles during ight.
The main components of the Vision System are located on the underside of the aircraft body. This
includes a camera
2
and a 3D infrared module
3
. The Vision System uses 3D infrared module and
image data to help the aircraft maintain its current position, enabling precision hovering indoors or in
environments where GPS signal is not available.
The 3D Sensing System constantly scan for obstacles, allowing Spark to avoid obstacles when lighting is
sufcient.
1
2
3
Detection Range
The detection range of the 3D Sensing System is depicted below. Note that the aircraft cannot sense or
avoid obstacles that are not within the detection range.
Using the Vision System
The Vision System is activated automatically when the aircraft is turned on. No further action is required.
The Vision System can be used in indoor environments where GPS is unavailable. Using the Vision
System, the aircraft can hover precisely, even without GPS.
0.2- 5 m

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
