dji SPARK User Manual

12
©
2017 DJI All Rights Reserved.
Spark
User Manual
Follow the steps below to use the Vision System:
1. Ensure the aircraft is in P Mode and place the aircraft on a at surface. Note that the Vision System
cannot work properly on surfaces without clear pattern variations.
2. Turn on the aircraft. The aircraft will hover in place after takeoff. The aircraft status indicators will ash
green twice, which indicates the Vision System is working.
Powered by the 3D Sensing System, the aircraft is able to actively brake when obstacles are detected in
front. The 3D Sensing System works best when lighting is adequate and the obstacle is clearly marked or
textured. The aircraft must y at no more than 6.7 mph (10.8 kph) to allow for sufcient braking distance.
3D Sensing and Vision System performance are affected by the type of surface being own over.
The aircraft will switch from P Mode to ATTI Mode automatically if neither GPS or Vision System
are available. Please be vigilant when operating Spark in the following situations:
Flying at high speeds below 0.5 meters.
Flying over monochrome surfaces (e.g., solid black, solid white, solid red, or solid green).
Flying over highly reective surfaces.
Flying over water or transparent surfaces.
Flying over moving surfaces or objects.
Flying in an area where the lighting changes frequently or drastically.
Flying over extremely dark (lux < 10) or bright (lux > 100,000) surfaces.
Flying over surfaces without clear patterns or texture.
Flying over surfaces with identical repeating patterns or textures (e.g., tiling).
Flying over small and ne objects (e.g. tree branches and power lines).
Flying at speeds of over 6.7 mph (10.8 kph) at 2 meters above the ground.
Keep sensors clean at all times. Dirt or other debris may adversely affect their effectiveness.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
