Spark User Manual
4. Then the front LEDs turn solid red after blinking green. When the status LED on the remote controller
turns solid green, linking is complete.
Ensure the remote controller is within 0.66 ft (20 cm) of the aircraft during linking.
Disconnect the Remote Controller
Apart from using the remote controller, you can control the aircraft using virtual joysticks in DJI GO 4.
However, when the remote controller is linked to the aircraft, virtual joystick control is disabled. You need
to disconnect the remote controller and aircraft to enable virtual joysticks.
1. Power on the aircraft.
2. Press and hold the power button of the Intelligent Flight Battery for six seconds until hearing a double
beep, which will disconnect the remote controller and aircraft.
Connect the aircraft’s Wi-Fi network after disconnecting the remote controller to use virtual joysticks.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
