dji SPARK User Manual

©
2017 DJI All Rights Reserved.
51
Spark User Manual
Ensure the aircraft is connected to your computer before powering on.
The rmware update will take around 15 minutes. It is normal that the gimbal goes limp, aircraft
status indicators blink abnormally, and the aircraft reboots. Please wait patiently until the update
is complete.
Ensure the computer has access to the Internet.
Ensure the Intelligent Flight Battery has at least 50% power and the remote controller has at
least 30% power.
Do not disconnect the aircraft from the computer during an update.
1. With the aircraft powered off, connect the aircraft to a computer via the Micro USB port using a Micro
USB cable.
2. Power on the aircraft.
3. Launch DJI Assistant 2 and login with your DJI account.
4. Select Spark and click on Firmware Updates on the left panel.
5. Select the rmware version that you wish to update.
6. Wait for the rmware to be downloaded and the rmware update will start automatically.
7. Reboot the aircraft after the rmware update is complete.

dji SPARK Specifications

Operating Environment

max speed	31 mph (50 kph)
operating temperature	32° to 104° F (0° to 40° C)
charging temperature	41° to 104° F (5° to 40° C)

Camera

sensor	1/2.3” CMOS
effective pixels	12 Megapixels
video recording modes	FHD: 1920×1080 30p

Power

charger input	100-240 V, 50/60 Hz, 0.5 A
charger output	5 V 3 A / 9 V 2A / 12 V 1.5 A
battery capacity	1480 mAh

Remote Control

operating frequency	2.4G / 5.8G
max transmission distance (Wi-Fi)	100 m (Distance), 50 m (Height)
max transmission distance (Remote Controller)	2000 m

Weight and Dimensions

weight	300 g
dimensions	143×143×55 mm
