dji ZENMUSE P1 - Image Log File

©
2021
DJI All Rights Reserved.
23
ZENMUSE P1 User Manual
DewarpFlag Whether the camera parameters have been dewarped or not:
0 - Not dewarped
1 - Dewarped
DewarpData Camera parameters for dewarping (the calibration file must be
imported and calibrated in DJI Terra for the data to be generated):
Parameter sequence - fx, fy, cx, cy, k1, k2, p1, p2, k3
fx, fy - Calibrated focal length (unit: pixel)
cx, cy - Calibrated optical center position (unit: pixel, origin point:
photo center)
k1, k2, p1, p2, k3 - Radial and tangential distortion parameters
UTCAtExposure UTC when the camera is exposed.
ShutterType Shutter type
ShutterCount Shutter count used
CameraSerialNumber Camera serial number
LensSerialNumber Lens serial number
DroneModel Aircraft model
DroneSerialNumber Aircraft serial number
Image Log File
Open an image log le with the extension .MRK to view the data below.
