2021

Product Prole

Introduction

The Zenmuse P1 integrates a 45MP full-frame sensor, a global mechanical shutter, and an

interchangeable xed-focus DJI DL Lens (ENTERPRISE) on a 3-axis stabilized gimbal. Designed to be

used with compatible DJI aircraft and DJI TERRA

for photogrammetry ight missions, the P1 takes

eciency and accuracy to a whole new level.

* DO NOT press the lens release button while attaching the lens.

1. Gimbal Connector

2. Pan Motor

3. Roll Motor

4. Lens Release Button*

5. Tilt Motor

6. Lens Mounting Index

7. Lens Mount

8. Lens Mounting Index

9. Lens

10. Lens Hood Mounting Index

11. Balancing Ring

12. Lens Hood

13. Lens Cap

14. SD Card Slot

15. microSD Card Slot

14 15

Other manuals for dji ZENMUSE P1

Questions and Answers:

Need help?

Do you have a question about the dji ZENMUSE P1 and is the answer not in the manual?

General

Country of origin	China
Power consumption (max)	20 W
Product color	Black
Compatible products	DJI Matrice 300 RTK
International Protection (IP) code	IPX4
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	-20 - 60 %
Megapixel	45 MP
Maximum image resolution	8192 x 5460 pixels
ISO sensitivity	100, 25600
Image stabilizer	Yes
Maximum aperture number	16
Minimum aperture number	2.8
Field of view (FOV) angle	63.5 °
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	1 s
Compatible memory cards	SD
Maximum memory card size	512 GB
Maximum frame rate	60 fps
Video formats supported	MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Mechanical pan range	-320 - 320 °
Mechanical roll range	-55 - 55 °
Mechanical tilt range	-130 - 40 °
Wi-Fi	-
