ZENMUSE P1 User Manual
Gimbal Rotating Range
The 3-axis gimbal provides a stable and mobile platform for the camera system to capture smooth
images and videos. The tilt, pan, and roll ranges are listed below.
Take o from at and open ground. DO NOT block or touch the gimbal after powering on.
Make sure that the SD card cover is closed properly. Otherwise, it may obstruct the rotation
of the gimbal.
Horizon
+
40°
+
55°
-
55°
+
320°
-
320°
0°
-125°

dji ZENMUSE P1 Specifications

General

Country of origin	China
Power consumption (max)	20 W
Product color	Black
Compatible products	DJI Matrice 300 RTK
International Protection (IP) code	IPX4
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	-20 - 60 %
Megapixel	45 MP
Maximum image resolution	8192 x 5460 pixels
ISO sensitivity	100, 25600
Image stabilizer	Yes
Maximum aperture number	16
Minimum aperture number	2.8
Field of view (FOV) angle	63.5 °
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	1 s
Compatible memory cards	SD
Maximum memory card size	512 GB
Maximum frame rate	60 fps
Video formats supported	MOV, MP4
Maximum video resolution	3840 x 2160 pixels
Mechanical pan range	-320 - 320 °
Mechanical roll range	-55 - 55 °
Mechanical tilt range	-130 - 40 °
Wi-Fi	-

Weight and Dimensions

Depth	129 mm
Width	166 mm
Height	198 mm
Weight	800 g
