When setting timer, displaying the rated
time. When the timer function is
switched ON, displaying remaining time.
Table 3
5. Installation and Operation
5.1 Installation
• Adjustable base (Figure 6).
Figure 6
CAUTION! Loosen transportation lock (Figure 7).
• Hold the lift with your hand on the height position and
remove the thumb screw on the back of the appliance
(a).
• Once the transportation lock has been removed, the lift
moves slowly to its upper end position. The distance is
150mm.
• Connect the device to the power supply using power
cable (b).
• Connect the heating bath to the device (c).
Figure 7
