FIG 1 MPS49 FRONT PANEL
1. Electrical ground connector
2. External power socket
3. AC power LED
4. Fuse
5. Power button
6. Drain valve
7. Drain button
8. Vacuum port
9. Battery compartment
10. Static line outputs
11. AoA line outputs
12. Pitot line outputs
13. Additional communication ports
14. RS232 port
15. Manual vent valves
16. Display
17. Keyboard
FIG 2 KEYBOARD LAYOUT
D.Marchiori Copyright 14
1
2
3
4
5
7
8
6
9
10 11 12
13
15
16
17
14
