36 EPT034331 Issue 5 May 2021
SPECIFICATION
Temperature Range
(Working):
+5º to +45ºC (42ºF to 112ºF)
Temperature Range
(Storage):
-20º to +60ºC (-4ºF to +140ºF) (machine dry - storage, wet
dependent upon fluids)
Humidity: 0 - 90% RH (non-condensing)
Pollution Degree of
Intended Environment:
Degree 2
Maximum Altitude of
Operation:
< 2000m
Intended Environment: Indoors only
Electrical Supply: 100-240V 50-60Hz (nominal), 4A, single phase Auto ranging
Overvoltage Category: CAT II
Power Consumption: 40 Watt (idle)
80 Watt (printing)
RF Frequency (QMM): 13.56MHz
RF Power (QMM): 62μW
Acoustic Noise Level: Not more than 70 dBA
TouchScreen 10" Power
Supply:
24 VDC, 15W, 500mA over non standard DVI
Mains voltage deviation: -10% to +6%
Note: The power supply contains “reinforced” insulation.
TouchScreen 7" Power
Supply:
24 VDC, 12W, 500mA over non standard DVI
Mains voltage deviation: -10% to +6%
Note: The power supply contains “reinforced” insulation.
