Domino C6000 plus - Page 140

DIMENSION DRAWINGS
140 77144 Issue 8 August 2009
29 (1.14)
35.35 (1.39)
50 (1.97)
50 (1.97)
100 (3.93)
20 (0.79) 20 (0.79)
50 (1.96)
245 (9.6)
M8 x4 off
29 (1.14)
35.35 (1.39)
50 (1.97)
100 (3.94)
M8 x4 off
50 (1.97)50 (1.97)
100 (3.93)
20 (0.79) 20 (0.79)
Single Mounting Bracket
Double Mounting Bracket
Mounting Brackets
