C1000X & C3000X PRINT HEAD POSITIONING
77144 Issue 8 August 2009 137
C1000X & C3000X
PRINT HEAD POSITIONING
Mounting Plate
Mounting Plate
Print Head Mounting Position When Printing Horizontal
When printing horizontal − Head is mounted in
position "A" and mounting plate is off−set downwards
as shown. Product sensor (if head mounted) is set horizontal.
Product/
Subtrate
Position A
Print
Head
Product
Sensor
