C1000X & C3000X PRINT HEAD POSITIONING
138 77144 Issue 8 August 2009
Mounting Plate
Mounting Plate
Print Head Mounting Position When Printing Downwards
When printing downwards − Head is mounted in position "B"
and mounting plate is inverted to upwards off−set position
as shown. Product sensor (if head mounted) is rotated as shown.
Position B
Print
Head
Product
Sensor
Product/
Subtrate
