FAULT FINDING AND REPAIR
4-34 20509 Issue 7 Jan 2018
Where a printer is installed with the VBB Battery link already set to ON, the
first prints should be checked to make sure the existing Print Go is
satisfactory.
LK1
Motherboard
1234
OFF
LED 1 LED 2
RV2
RV1
R/POT
B
C
A
LK2 E C A
FDB
G
VBB BATTERY LINK
ON VBB
ROM
RAM
AB
LK5
LK4
LK3
128 512
SW1
LK6
INT REM
KEY
U/P LINK
LMNPJKWXYZ
LK
7
CD
AB
4-34.epc
Universal Serial Interface PCB Link and
Switch Settings for blue T14 Pocket Terminal
