DOMUSA Evolution EV AC - 17 Technical Characteristics

Evolution EV AC
22
17 TECHNICAL CHARACTERISTICS
EVOLUTION EV 25 AC EV 35 AC
Condensation
Boiler type -
Heating only
Nominal energy consumption kW 28.2 38.6
Nominal output power kW 27.4 37.5
Heating temperature adjustment ºC 30 - 85
Maximum safety temperature ºC 110
Maximum pressure for heating mode bar 3
Heating expansion vessel capacity Lts 8 12
Heating water volume Lts 30 43
Water pressure drop mca 0.25 0.35
Fume temperature ºC 76 83
Volume on fume side Lts 24 31
Maximum fume flow Kg/s 0.0125 0.0140
Fume pressure drop mmH
2
O 2.8 2.95
CO levels mg/kWh 58 52
NOx levels mg/kWh 94.5 81.7
NOx class (acc. EN 303-2) - 3
Combustion chamber length mm 255 355
Combustion chamber type - wet, +1 exhaustion duct
Domestic burner model - D-3 D-4
Burner adjustment type - ON/OFF
Electrical supply - ~220-230 V - 50 Hz - 200 W
Gross weight Kg 145 165
EC certification nº
- RC 99BQ112
Nº of stars (acc. Directive 92/42/EEC) -

