A Series Diesel Engine Fuel System 91
24mm
Remove the valve.
Note : The Bosch VE valve is shown.
Caution : When removing the valve, be careful not
to drop the plunger and spring.
“Package” the solenoid, o-ring, spring and plunger.
24mm
Tighten the solenoid securely.
Connect the electric wire.
Torque Value: 20 Nm [15 ft-lbs]
To Next Page
