How to use the function button at analyzing the recording data of flight record
Function Button of Flight Record Data Analyzing Screen
After completing Flight Record, the screen is changed to <Figure 15-1> or <Figure 15-2>, as the recorded
Data can be analyzed.
<Figure 15-1: Data analyzing in graph mode>
<Figure 15-2: Data analyzing in text mode>
Play backward or stop.
Play forward or stop.
Scale up the analyzing Data on time axis.
Scale down the analyzing Data on time axis.
Resets the data recording condition.
Show the Function menu
* For details, refer to the “Function Menu of Flight Record Data Analyzing
Screen” described in next page.
